CARLIKE CL-HDHCF-11P HD Chrome Honeycomb Carbon Fiber Purple Vinyl PET Liner
Series: 3000P
Brand: CARLIKE
Color: HD Chrome Honeycomb Carbon Fiber Purple PET
Model number: CL-HDHCF-11P
Characteristic: Super stretch, incredible restorable
Performance level: Premium+
Film produce technology: Calendered
Film thickness: 160micron, 6.4mil(with glue)
Release paper: 100G PET
Adhesive thickness: 30μm
Air bubble free: Yes
Application: Car wrap
Application temperature: From +80°С to +120°С
Temperature resistance: From -40°С to +120°С
Storing period: 2 years if stored in +10°С to +25°С, relative humidity 50%, in original package, away from direct sunlight, clean and dry place
Package: Full roll width 1.52m, length 17m, weight 13KG
Packing size: 1.55x0.18x0.18m
Remark: the full roll 1.52x17M/5x56FT usually is enough for wrap a full sedan or SUV. If your car is larger, please choose 1.52x23M/5x75FT, we will send 1.52x6M/5x19FT + 1.52x17M/5x56FT.
Quality warranty: 2 Years, during the quality warranty period, the film surface has no obvious fading, no cracking, and no residual glue on the car paint after removable.
| Data Sheet | |
| Surface | Opaque |
| Substrate material |
130Microns High Polymeric PVC |
| Pressure sensitive adhesive |
30μm Solvent-based Removable |
| Releaser liner | 100G PET High density air channels |
| Elongation at break |
300% |
| Tear strength | 37.2 N/10mm Test Method: ASTM D3759 |
| Glossiness | Gloss 95-110Gu Matte 5-30Gu |
| Viscosity | Initial tack:700-800g/25mm After 24 hours:1800-2000g/25mm After 3 months: 1500g/25mm |
| Peel strength | 2.5N/25mm Test Method: ASTM D3330 |
| Temperature resistance | -40°С to +120°С |
| Flourescent ultraviolet test |
Gray Level: 4-5 Test Method: ASTM D4329-13A |
Caution: The product images, colors on the screen are approximate. For the real representation of the product color, please check the color swatch.
1. Rich Purple with Reflective Chrome Honeycomb Pattern
The HD Chrome Honeycomb Carbon Fiber Purple Vinyl showcases a deep, luxurious purple base with a shimmering chrome honeycomb carbon fiber texture. This creates a striking 3D visual effect that enhances vehicle aesthetics.
2. PET Liner for Enhanced Application Stability
The vinyl comes with a PET release liner, offering excellent dimensional control and smooth handling. This ensures the honeycomb pattern remains precise and aligned, even on curved or contoured surfaces.
3. Bubble-Free Installation and Long-Lasting Durability
Featuring air-release technology, the vinyl allows easy, bubble-free installation. It is stretchable, repositionable, and removable without residue. With a 3–5 year lifespan, it maintains its vibrant purple sheen and texture outdoors.
