CARLIKE CL-HD3DU-24P HD Chrome Universe Carbon Fiber Matte Silver Vinyl PET Liner
Series: 3000P
Brand: CARLIKE
Color: HD Chrome Universe Carbon Fiber Matte Silver PET
Model number: CL-HD3DU-24P
Characteristic: Super stretch, incredible restorable
Performance level: Premium+
Film produce technology: Calendered
Film thickness: 160micron, 6.4mil(with glue)
Release paper: 100G PET
Adhesive thickness: 30μm
Air bubble free: Yes
Application: Car wrap
Application temperature: From +80°С to +120°С
Temperature resistance: From -40°С to +120°С
Storing period: 2 years if stored in +10°С to +25°С, relative humidity 50%, in original package, away from direct sunlight, clean and dry place
Package: Full roll width 1.52m, length 17m, weight 13KG
Packing size: 1.55x0.18x0.18m
Remark: the full roll 1.52x17M/5x56FT usually is enough for wrap a full sedan or SUV. If your car is larger, please choose 1.52x23M/5x75FT, we will send 1.52x6M/5x19FT + 1.52x17M/5x56FT.
Quality warranty: 2 Years, during the quality warranty period, the film surface has no obvious fading, no cracking, and no residual glue on the car paint after removable.
| Data Sheet | |
| Surface | Opaque |
| Substrate material |
130Microns High Polymeric PVC |
| Pressure sensitive adhesive |
30μm Solvent-based Removable |
| Releaser liner | 100G PET High density air channels |
| Elongation at break |
300% |
| Tear strength | 37.2 N/10mm Test Method: ASTM D3759 |
| Glossiness | Gloss 95-110Gu Matte 5-30Gu |
| Viscosity | Initial tack:700-800g/25mm After 24 hours:1800-2000g/25mm After 3 months: 1500g/25mm |
| Peel strength | 2.5N/25mm Test Method: ASTM D3330 |
| Temperature resistance | -40°С to +120°С |
| Flourescent ultraviolet test |
Gray Level: 4-5 Test Method: ASTM D4329-13A |
Caution: The product images, colors on the screen are approximate. For the real representation of the product color, please check the color swatch.
1. Sleek Matte Silver with Carbon Fiber Texture
The HD Chrome Universe Carbon Fiber Matte Silver Vinyl combines a cool, matte silver tone with a refined carbon fiber pattern. This finish offers a modern, industrial aesthetic—ideal for automotive wraps and high-end custom applications.
2. High-Performance Build with PET Liner
Crafted with advanced HD chrome carbon fiber technology, the vinyl includes a PET liner for superior handling and form stability. At 160 microns thick (6.4 mil with adhesive), it provides excellent protection while being flexible enough for curves and contours.
3. Easy Installation and Long-Lasting Results
Designed with air-release channels, the vinyl allows for a smooth, bubble-free application. It's stretchable, repositionable, and removable without leaving residue. With a lifespan of 3–5 years, it retains its matte finish and structural quality in various environments.
